Wireless loadshackle 3.25t with bobbin

Price: € 2 899,00

Article no:

WLS3,25T

Stock status:

4-8 days

Brand:

Straightpoint

Available in several variants

12ton bluetooth	WLS12T-BTE	€ 2 890,00
3,25ton	WLS3,25T	€ 2 899,00
12ton	WLS12T	€ 3 319,00
6,5ton	WLS6,5T	€ 3 319,00
25ton	WLS25T	€ 4 599,00
55ton	WLS55T	€ 6 645,00
85ton	WLS85T	€ 8 869,00
120ton	WLS120T	€ 13 490,00
200ton	WLS200T	€ 28 290,00
300ton	WLS300T	€ 35 920,00
400ton	WLS400T	€ 48 280,00
500ton	WLS500T	€ 56 170,00
400ton_w	WLS400TWB	€ 61 480,00

Description

Straightpoint’s Wireless Loadshackle provides the perfect solution to limited headroom applications. Each Wireless Loadshackle is proof tested, then equipped with a hard anodised aluminium electronics enclosure. Contained within this aluminium enclosure is a new internal chassis providing IP67/NEMA6 environmental protection even with the battery cover plate missing. Featuring industry leading wireless technology and range of 700m/2300ft, the Wireless Loadshackle is supplied with an update rate of 3Hz and can be easily configured to run at industry leading speeds of up to 200Hz.

BLUETOOTH OPTION IS AVAILABLE AND SUPPLIED WITH A FREE HHP FOR IOS AND ANDROID

Data is transmitted wirelessly utilising the latest in IEEE 802.15.4 (2.4 GHz) technology providing safe, high integrity, error free transmission of both static weight and dynamic load to a wireless handheld controller or wireless Windows PC data logging software package.

The Wireless Loadshackle may also be used with Straightpoint’s SW-PTP software package allowing the operator to perform load tests at a safe distance and generate real time test certificates on site. Straightpoint’s Wireless Loadshackle utilises easily sourced AA alkaline batteries and features advanced circuitry designed to protect the unit from damage associated with incorrectly installed batteries. This advanced circuitry extends battery life and the use of easily sourced alkaline batteries eliminates issues associated with rechargeable battery pack charging, failure and replacement. Straightpoint’s huge range of tooling allows the engineers to calibrate in shackle for extra accuracy unlike many other load cell manufacturers.

A full array of wireless accessories are also available including signal boosters, LED wireless scoreboards and base stations with analogue (4-20mA, 0-10v, 0-5v) or digital (RS232/485, Modbus RTU, and ASCII serial communications protocol) outputs.

FEATURES
